Injector Dynamics ID1750-XDS Direct Fit Injectors Set of 4

Subaru BRZ/Toyota 86

$1,974.95
%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E

Description

High-output Subaru BRZ and Toyota 86 engines on ethanol get ID1700-level flow with more even fuelling at low pulse widths from this direct-fit set of four Injector Dynamics ID1750-XDS injectors. Same fitment, better injector.

Pro Speed Racing is the official Main Wholesale Distributor for Injector Dynamics in Australia and New Zealand. The Injector Dynamics collection shows the complete range, while Pro Speed's general range of performance car parts covers far more.

Inside the box

  • Part number 1750.18.04.36.11.4
  • Four injectors
  • Direct fit for the BRZ and 86

Flow rate, rated pressure and connector all appear in Technical Specifications below.

Better than the ID1700

Injector Dynamics developed the ID1750-XDS as the successor to the ID1700. It offers a higher dynamic flow rate with no increase in minimum fuel mass, better balance between cylinders at low pulse widths and improved pressure sensitivity. The corrosion resistance that made the ID1700 popular is unchanged.

Before you order

Compare length and O-ring sizes with the injectors fitted now, and check the Vehicle Fitment tab for your model. For an even bigger fuel supply, the ID2600-XDS set for the BRZ and 86 is available, and more upgrades are in the Toyota 86 aftermarket parts collection.

Technical Specifications

  • Nominal Flow Rate: 1728cc/min @ 3.0 Bar (43.5 psi), Using E10 Emissions Certification Fuel at 49 Degrees C (120F)
  • Maximum Differential Fuel Pressure: 7.0 Bar (101.5 psi)
  • Electrical Connector: USCAR
  • Fuel Compatibility
    • Methanol
    • Ethanol
    • MTBE
    • Nitromethane
    • All Known Hydrocarbon Fuels.

Fitment Table
