| SKU:
1750.60.14.D.4
Injector Dynamics ID1750-XDS Direct Fit Injectors Set of 4
$1,224.00
Unit price
/
Unavailable
%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E
If your four-injector engine is set up for cushion-lower injectors and now needs far more fuel for boost and ethanol, this universal Injector Dynamics ID1750-XDS Direct Fit set of 4 is built around a 60mm body, a 14mm top and a Denso-style lower cushion. Four in the box; your tuner handles the rest.
Pro Speed Racing is the official Main Wholesale Distributor in Australia and New Zealand for Injector Dynamics, the company that designs and builds these injectors. More direct-fit and universal sets are in the Injector Dynamics product collection .
Specs: 1750.60.14.D.4
Part number 1750.60.14.D.4
Set of four
60mm long
14mm top O-ring
Denso-style cushion lower
Flow rating, maximum differential pressure and connector type sit under Technical Specifications below.
Improvements on the ID1700 Injector Dynamics positions the ID1750-XDS as the next step from the ID1700-XDS. Pressure sensitivity is improved, cylinders are better balanced at low pulsewidths, and dynamic flow rises without any increase in minimum fuel mass. The corrosion-resistant internals mean it handles everything from petrol to ethanol blends.
Vehicle fit and spares Look at the Vehicle Fitment tab for the vehicles this set covers, and compare length and top and lower sizes against the injectors in your engine, as some models have more than one possible size. A single replacement in the same configuration is the ID1750-XDS 60mm single with purple adaptor top and Denso cushion .
Nominal Flow Rate: 1728cc/min @ 3.0 Bar (43.5 psi), Using E10 Emissions Certification Fuel at 49 Degrees C (120F)
Maximum Differential Fuel Pressure: 7.0 Bar (101.5 psi)
Electrical Connector: USCAR
Fuel Compatibility
Methanol
Ethanol
MTBE
Nitromethane
All Known Hydrocarbon Fuels.
