Injector Dynamics ID1750-XDS Direct Fit Injectors Set of 5 - Ford Focus XR5 LS/LT/LV

Ford Focus XR5 LS/LT/LV
$2,464.95
%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E

Description

Your Ford Focus XR5 LS/LT/LV gets five Injector Dynamics ID1750-XDS injectors in this direct-fit set, the replacement for the ID1700. It suits boosted XR5 builds on E85 that need more fuel without losing control down low.

Pro Speed Racing is Injector Dynamics' official Main Wholesale Distributor for Australia and New Zealand, so the full Injector Dynamics injector line-up is supplied locally, next to everything else in Pro Speed's performance car parts range.

Part number 1750.60.14.14.5, decoded

  • 60: body length in millimetres
  • 14.14: 14mm top and 14mm lower O-rings
  • 5: injectors in the set

Flow, maximum pressure and plug type are covered in Technical Specifications below.

What changed from the ID1700

Injector Dynamics lists three gains over the ID1700: more dynamic flow with no rise in minimum fuel mass, tighter cylinder-to-cylinder balance at low pulse widths, and better pressure sensitivity. The corrosion resistance carries over unchanged, which the manufacturer sums up as compatible with everything but dirt. Hard to argue with that.

Before it goes in

Measure the injectors currently in your XR5 against the 60mm length and 14mm seals, and cross-check the Vehicle Fitment tab. Working on an Audi RS3 or TT RS instead of the Focus? That five-cylinder has its own ID1750-XDS set of five for the RS3 and TT RS.

Technical Specifications

  • Nominal Flow Rate: 1728cc/min @ 3.0 Bar (43.5 psi), Using E10 Emissions Certification Fuel at 49 Degrees C (120F)
  • Maximum Differential Fuel Pressure: 7.0 Bar (101.5 psi)
  • Electrical Connector: USCAR
  • Fuel Compatibility
    • Methanol
    • Ethanol
    • MTBE
    • Nitromethane
    • All Known Hydrocarbon Fuels.
