 |  SKU: 1750.60.14.D.6

Injector Dynamics ID1750-XDS Direct Fit Injectors Set of 6 - Nissan Skyline R32/R33/R34 (w/14mm Top O-Ring)

Nissan Skyline R32/R33/R34 (w/14mm Top O-Ring)

$2,949.95
%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E

Description

An E85 Nissan Skyline R32, R33 or R34 with a 14mm top O-ring making big power is the build this direct-fit set of six Injector Dynamics ID1750-XDS injectors is for. It's the newest step up from the ID1700-XDS.

Pro Speed Racing is the official Main Wholesale Distributor in Australia and New Zealand for Injector Dynamics, whose injector and fuel system collection covers the full range.

The six-injector fitment

  • Part number 1750.60.14.D.6
  • 6 x ID1750-XDS injectors
  • 60mm length
  • 14mm top O-ring
  • Denso-style lower cushion

Check Technical Specifications below for the rated flow, pressure and connector.

ID1750-XDS versus the ID1700-XDS

Injector Dynamics developed the ID1750-XDS as the next step from the ID1700-XDS. It brings more dynamic flow without lifting minimum fuel mass, closer cylinder balance at low pulse widths and better pressure sensitivity, while keeping the corrosion resistance that made the ID1700-XDS work with practically any fuel. For a Skyline on a big ethanol tune, that low pulse-width balance is what keeps idle and cruise civil.

Skyline fitment

Some vehicles can take more than one injector size, so compare the 60mm length, 14mm top and lower cushion with the injectors fitted now and check the Vehicle Fitment tab. Top seals wear over time; the 14mm Viton top O-ring is sold individually, and the Skyline aftermarket parts range has more for your car.

Technical Specifications

  • Nominal Flow Rate: 1728cc/min @ 3.0 Bar (43.5 psi), Using E10 Emissions Certification Fuel at 49 Degrees C (120F)
  • Maximum Differential Fuel Pressure: 7.0 Bar (101.5 psi)
  • Electrical Connector: USCAR
  • Fuel Compatibility
    • Methanol
    • Ethanol
    • MTBE
    • Nitromethane
    • All Known Hydrocarbon Fuels.

Fitment Table
