JE Pistons Forged Piston Set 82.5mm Bore w/21mm Pin
Audi/VW (2.0 TFSI/TSI EA888)
Product will be in stock soon.
This product is in stock & ready to be delivered.
This product has very limited stock remaining.
This product is not available at this time.
Description
Description
With a history of proven performance and racing championships a mile wide, Audi and Volkswagen are known forces to be reckoned with. Their huge following of builders, tuners, and enthusiasts demand the best, and JE pistons brings nothing less to the table. JE’s Audi and Volkswagen pistons are designed to take the abuse of racing, big boost, high RPM, and increased horsepower in stride. They feature our patented Perfect Skirt ® piston coating, an advanced Forged Side Relief (FSR) forging and are significantly bolstered in key areas such as the ring lands and crown for increased rigidity. All piston set includes carbon steel wrist pins, premium carbon steel gas nitrided piston rings, and locks.
Technical Specifications
Technical Specifications
Bore Diameter | 82.50 |
---|---|
Compression Height | 1.165 |
Piston Head Type | Dish |
Piston Volume | -7.1 |
Cylinder Head | 2.0 TSI |
Piston Pin Outside Diameter | 0.827 |
Piston Pin Length | 2.250 |
Piston Pin Material | 5115 |
Ringset Included | Yes |
Top Compression Ring Thickness | 0.04 |
Second Compression Ring Thickness | 0.048 |
Oil Ring Thickness | 0.111 |
Piston Material | 2618 |
Forging Type | Round |
Piston Avg Weight | 320 |
Pin Wall Thickness | 0.150 |
Product Market | Sport Compact |
Product Types | Piston Kits |
