Most would agree that the time and stress to remove and replace bushings and ball joints to suspension arms can be hard to justify. Making up press tools and damaging arms are just two of the problems one can endure. Why put yourself through it when you can purchase complete arms, fitted with market leading Whiteline synthetic elastomer bushings and premium quality ball joints (if applicable).
Features:
Protective E-Coat coating acts as a hard skin that is much tougher than conventional paint allowing this product to withstand the toughest conditions and resist corrosion for years to come.
Protective plating on all metal components acts as a hard skin that is much tougher than conventional paint allowing this product to withstand the toughest conditions and resist corrosion for years to come.
Whiteline's latest technology synthetic elastomer formulation boasts resistance to oil, grease, ozone and weathering.
Supplied with extreme pressure molybdenum disulphide (LM) based grease for extended life.
Internal grease reservoirs provide continual self-lubrication for optimum friction management.
Specially bonded design for optimised strength typically required in high load bearing applications.
Designed with the installer in mind by reducing the need of specialised skills, tools and equipment.
This Whiteline kit is covered by a 3 Year / 60,000kms warranty including parts and labour.
Kit Includes:
1 Arm, Grease
Alignment Change:
N/A
Service Kit:
N/A
Installation:
Fitment Time (Hours): 1
Degree Of Fitment Difficulty: DIY - With Specialist Tools
Fitment Notes: N/A
Wheel Alignment Required: Yes
Vehicle Fitment and Important Notes:
1999-2003 HOLDEN CAPRICE WH 6/8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2003-2004 HOLDEN CAPRICE WK 6/8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2004-2006 HOLDEN CAPRICE WL 6/8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
1997-2002 HOLDEN COMMODORE VT, VX, VU 6/8CYL (Suits VT series 2 - on (threaded ball joint) - Left hand side only. Complete arm fitted with bushings and ball joint)
2002-2006 HOLDEN COMMODORE VY, VZ 6/8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2003-2006 HOLDEN CREWMAN VY, VZ RWD 6/8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2001-2004 HOLDEN MONARO V2 6/8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2004-2006 HOLDEN MONARO VZ 8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
1999-2003 HOLDEN STATESMAN WH 6/8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2003-2004 HOLDEN STATESMAN WK 6/8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2004-2006 HOLDEN STATESMAN WL 6/8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
1997-2002 HSV CLUBSPORT VT, VX 8CYL (Suits VT series 2 - on (threaded ball joint) - Left hand side only. Complete arm fitted with bushings and ball joint)
2002-2006 HSV CLUBSPORT Y SERIES, Z SERIES 8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2001-2004 HSV COUPE V2 8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2004-2007 HSV COUPE Z SERIES 8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
1999-2003 HSV GRANGE WH 6/8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2003-2004 HSV GRANGE WK 8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2004-2006 HSV GRANGE WL 8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
1997-2000 HSV GTS VT 8CYL (Suits series 2 models (threaded ball joint) - Left hand side only. Complete arm fitted with bushings and ball joint)
2000-2001 HSV GTS VX 8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2002-2004 HSV GTS Y SERIES 8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2001-2002 HSV MALOO VU 8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2002-2007 HSV MALOO Y SERIES, Z SERIES 8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
1997-2002 HSV SENATOR VT, VX 8CYL (Suits VT series 2 - on (threaded ball joint) - Left hand side only. Complete arm fitted with bushings and ball joint)
2002-2006 HSV SENATOR Y SERIES, Z SERIES 8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
1999-2000 HSV SV99 VT 8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2001-2001 HSV SV300 VX 8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
2005-2006 HSV SV6000 Z SERIES 8CYL (Left hand side only. Complete arm fitted with bushings and ball joint)
1998-2002 HSV XU6 VT, VX 6CYL (Suits VT series 2 - on (threaded ball joint) - Left hand side only. Complete arm fitted with bushings and ball joint)
Technical Specifications
Kit Specifications:
KIT QTY
BUSH QTY
OD (A)
ID (B)
LENGTH (C)
FLANGE THICKNESS (D)
FLANGE OD
C/TUBE QTY
C/TUBE OD x ID x LENGTH
COMMENTS
1
1
Complete Suspension Arm
Arm Specifications:
ARM TYPE
UNITS
INCL BALL JOINT
ADJUSTABLE
Replacement
Single
Yes
No
Fitment Table
<div class="dynamic-checkout__content" id="dynamic-checkout-cart" data-shopify="dynamic-checkout-cart"> <shopify-accelerated-checkout-cart wallet-configs="[{"supports_subs":true,"supports_def_opts":false,"name":"shop_pay","wallet_params":{"shopId":84839039279,"merchantName":"Pro Speed Racing","personalized":true}},{"supports_subs":false,"supports_def_opts":false,"name":"paypal","wallet_params":{"shopId":84839039279,"countryCode":"AU","merchantName":"Pro Speed Racing","phoneRequired":true,"companyRequired":false,"shippingType":"shipping","shopifyPaymentsEnabled":true,"hasManagedSellingPlanState":null,"requiresBillingAgreement":false,"merchantId":"LXXML66B2BYR4","sdkUrl":"https://www.paypal.com/sdk/js?components=buttons\u0026commit=false\u0026currency=AUD\u0026locale=en_US\u0026client-id=AfUEYT7nO4BwZQERn9Vym5TbHAG08ptiKa9gm8OARBYgoqiAJIjllRjeIMI4g294KAH1JdTnkzubt1fr\u0026merchant-id=LXXML66B2BYR4\u0026intent=authorize"}}]" access-token="706ba983f15457e978c8a1c115b311ae" buyer-country="AU" buyer-locale="en" buyer-currency="AUD" shop-id="84839039279" cart-id="080597e3b9a87c3d9c9c5d1e042ff5a4" enabled-flags="["d6d12da0","32a68cd0","a1c7ccbe","ce346acf","c0874428"]" > <div class="wallet-button-wrapper"> <ul class='wallet-cart-grid wallet-cart-grid--skeleton' role="list" data-shopify-buttoncontainer="true"> <li data-testid='grid-cell' class='wallet-cart-button-container'><div class='wallet-cart-button wallet-cart-button__skeleton' role='button' disabled aria-hidden='true'> </div></li><li data-testid='grid-cell' class='wallet-cart-button-container'><div class='wallet-cart-button wallet-cart-button__skeleton' role='button' disabled aria-hidden='true'> </div></li> </ul> </div> </shopify-accelerated-checkout-cart> <small id="shopify-buyer-consent" class="hidden" aria-hidden="true" data-consent-type="subscription"> One or more of the items in your cart is a deferred, subscription, or recurring purchase. By continuing, I agree to the <span id="shopify-subscription-policy-button">cancellation policy</span> and authorize you to charge my payment method at the prices, frequency and dates listed on this page until my order is fulfilled or I cancel, if permitted. </small> </div>
| SKU:
WA130AL
