 |  SKU: 1050.48.14.15

Injector Dynamics ID1050-XDS 48mm Single Injector w/14mm Grey Adaptor Top, 15mm Lower O-Ring

Universal
$244.95
%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E

Description

One dud injector shouldn't end your day early, which is where this universal 48mm Injector Dynamics ID1050-XDS single comes in, with a 14mm grey adaptor top and a 15mm lower O-ring. Use it to replace one injector in a matching set, or keep it as a spare for this mid-length configuration.

Injector Dynamics makes it, and Pro Speed Racing is the official Main Wholesale Distributor for the brand across Australia and New Zealand, with the complete Injector Dynamics lineup online.

Specs for part 1050.48.14.15

  • Single ID1050-XDS injector
  • 48mm length
  • 14mm grey adaptor top
  • 15mm lower O-ring

Flow, maximum pressure and plug type are all in Technical Specifications below.

Not a modified production injector

Injector Dynamics is clear that the ID1050-XDS was built to a motorsport specification with Bosch Motorsport rather than adapted from a production component. It succeeds the ID1000 with a stronger magnetic circuit for stable operation up to its maximum rated pressure, an internal flow path improved for roughly 5% more output while keeping low-flow behaviour, and a replaceable inlet filter for longer service life.

Fitment and the larger sibling

Check the injector you're replacing for length, top size and lower O-ring, and see the Vehicle Fitment tab, since some vehicles can take more than one size. The same grey-top, 15mm-lower layout is offered in a larger flow size as the ID1300-XDS 48mm single injector, worth a look if your tuner says the 1050 is running out of room.

Technical Specifications

  • Nominal Flow Rate: 1065cc/min @ 3.0 Bar (43.5 psi) Using Gasoline at 52 Degrees C (125 Degrees F)
  • Maximum Differential Fuel Pressure: 10.0 Bar (145.0 psi)
  • Fuel Compatibility: Compatible With All Known Fuels
  • Electrical Connector: USCAR
