 |  SKU: 1750.48.11.14

Injector Dynamics ID1750-XDS 48mm Single Injector w/11mm Red Adaptor Top, 14mm Lower O-Ring - Universal

Universal
$514.95
%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E

Description

Tuners rebuilding a set after damage, or holding a spare for an E85 race car, reach for singles like this universal 48mm Injector Dynamics ID1750-XDS with a red 11mm adaptor top and a 14mm lower O-ring.

Every ID injector comes from Injector Dynamics. Pro Speed Racing's role is official Main Wholesale Distributor for the brand in Australia and New Zealand, and the Injector Dynamics catalogue at Pro Speed Racing covers the rest of the line. Pro Speed Racing's other performance parts are there when the job grows beyond one injector.

1750.48.11.14 specs

  • Part number 1750.48.11.14
  • Single injector
  • 48mm body length
  • Top: 11mm red adaptor
  • Lower: 14mm O-ring

Rated flow, pressure and connector information is in the Technical Specifications panel.

Corrosion resistance carried over

Ethanol doesn't scare it. Injector Dynamics says the ID1750-XDS keeps the "compatible with everything but dirt" corrosion resistance that made the ID1700 famous, so ethanol blends aren't a worry for the internals. On top of that, it gains dynamic flow with the same minimum fuel mass, better low-pulsewidth balance and improved pressure sensitivity.

Fitment and alternatives

Check the 48mm length and both O-ring sizes against your current injectors and on the Vehicle Fitment tab. For a lower-flow version with the same red top and 14mm lower, see the ID1050-XDS 48mm single.

Technical Specifications

  • Nominal Flow Rate: 1728cc/min @ 3.0 Bar (43.5 psi), Using E10 Emissions Certification Fuel at 49 Degrees C (120F)
  • Maximum Differential Fuel Pressure: 7.0 Bar (101.5 psi)
  • Electrical Connector: USCAR
  • Fuel Compatibility
    • Methanol
    • Ethanol
    • MTBE
    • Nitromethane
    • All Known Hydrocarbon Fuels.
