 |  SKU: 1750.48.14.14

Injector Dynamics ID1750-XDS 48mm Single Injector w/14mm Grey Adaptor Top, 14mm Lower O-ring - Universal

Universal
$514.95
%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E

Description

Boosted E85 engines that need one replacement injector, or a spare to keep with the car's service kit, are covered by this universal single Injector Dynamics ID1750-XDS with a 48mm body, a grey 14mm adaptor top and a 14mm lower O-ring.

As the official Main Wholesale Distributor for Injector Dynamics in Australia and New Zealand, Pro Speed Racing supplies the full Injector Dynamics range. Compare sizes in the Injector Dynamics section.

Part 1750.48.14.14 specs

  • Part number 1750.48.14.14
  • 1 x ID1750-XDS
  • 48mm length
  • 14mm top, grey adaptor
  • 14mm lower O-ring

The flow rate, pressure rating and connector are in the Technical Specifications panel lower down.

Made for boost and ethanol

Injector Dynamics built its predecessor, the ID1700, as an all-fuel injector for very high flow, mostly delivering E85 to boosted engines. The ID1750-XDS adds higher dynamic flow without raising minimum fuel mass, better cylinder balance at small pulsewidths and lower pressure sensitivity, with the same corrosion-resistant internals.

Check the lower O-ring

Grey top, 14mm lower. That lower is the one to check. Grey-top 48mm ID injectors come with different lowers, so compare length and both O-ring sizes with the injectors currently fitted and check the Vehicle Fitment tab. The ID1050-XDS 48mm with grey top is a lower-flow alternative, but note it uses a 15mm lower O-ring.

Technical Specifications

  • Nominal Flow Rate: 1728cc/min @ 3.0 Bar (43.5 psi), Using E10 Emissions Certification Fuel at 49 Degrees C (120F)
  • Maximum Differential Fuel Pressure: 7.0 Bar (101.5 psi)
  • Electrical Connector: USCAR
  • Fuel Compatibility
    • Methanol
    • Ethanol
    • MTBE
    • Nitromethane
    • All Known Hydrocarbon Fuels.

Fitment Table
