 |  SKU: 1750.60.11.14

Injector Dynamics ID1750-XDS 60mm Single Injector w/11mm Blue Adaptor Top, 14mm Lower O-Ring - Universal

Universal
$514.95
%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E

Description

High-output engines running ethanol fuels under boost, and needing one replacement or spare in this layout, are where this universal 60mm Injector Dynamics ID1750-XDS single fits in, with a blue 11mm adaptor top and a 14mm lower O-ring.

Injector Dynamics creates the product, and Pro Speed Racing distributes it as the official Main Wholesale Distributor for Australia and New Zealand. All flow sizes are in the Injector Dynamics area of the Pro Speed Racing site.

Single injector specs

  • Part 1750.60.11.14
  • 60mm length
  • 11mm top on a blue adaptor
  • 14mm lower O-ring

Technical Specifications below lists the flow rate, maximum pressure and connector.

Bosch Motorsport roots

High fuel pressure is home turf for this family. The ID1750-XDS descends from the ID1700, a product of the Injector Dynamics partnership with Bosch Motorsport, and Injector Dynamics notes the ID1700 already excelled at the pressures used in current systems. The ID1750-XDS builds on that with improved pressure sensitivity, more dynamic flow at the same minimum fuel mass and better balance at short pulsewidths.

Sizing it up

Compare length and O-ring sizes with the injectors already in your car and check the Vehicle Fitment tab. A smaller-flow 60mm alternative with the blue 11mm top is the ID1050-XDS single fitted with an O-ring retainer.

Technical Specifications

  • Nominal Flow Rate: 1728cc/min @ 3.0 Bar (43.5 psi), Using E10 Emissions Certification Fuel at 49 Degrees C (120F)
  • Maximum Differential Fuel Pressure: 7.0 Bar (101.5 psi)
  • Electrical Connector: USCAR
  • Fuel Compatibility
    • Methanol
    • Ethanol
    • MTBE
    • Nitromethane
    • All Known Hydrocarbon Fuels.
