Injector Dynamics ID1750-XDS Direct Fit Injectors Set of 2 - Polaris XP 1000/XP 4 1000/Can Am Maverick Turbo

Polaris XP 1000/XP 4 1000/Can Am Maverick Turbo

$994.95
%3Cp%3EEarn%20[points_amount]%20when%20you%20buy%20this%20item.%3C/p%3E

Description

Ethanol-fuelled Polaris XP 1000, XP 4 1000 and Can-Am Maverick Turbo builds that need ID1700-class flow, but still want clean running at idle and light load, are what this set of two Injector Dynamics ID1750-XDS injectors in the 34mm size is for.

Pro Speed Racing is the official Main Wholesale Distributor for Injector Dynamics in Australia and New Zealand. Every other size is listed in the Injector Dynamics range, and there are more performance parts across the Pro Speed store.

Set details

  • Part number 1750.34.14.14.2
  • Two injectors
  • 34mm length
  • 14mm top O-ring
  • 14mm lower O-ring

Flow and pressure ratings, plus the connector style, appear under Technical Specifications below.

Successor to the ID1700

Injector Dynamics replaced the ID1700 with the ID1750-XDS and lists three improvements: more dynamic flow without any increase in minimum fuel mass, better cylinder-to-cylinder balance at low pulse widths, and less pressure sensitivity. The corrosion resistance carries over, which Injector Dynamics describes as compatible with everything but dirt.

Sizing for your machine

Check the 34mm length and 14mm O-rings against the injectors fitted now, and confirm the model on the Vehicle Fitment tab. If the machine needs to drive well on petrol, the ID1300-XDS set of two for the XP 1000 is the better fit. For the largest fuel demand in this size, see the ID2600-XDS pair.

Technical Specifications

  • Nominal Flow Rate: 1728cc/min @ 3.0 Bar (43.5 psi), Using E10 Emissions Certification Fuel at 49 Degrees C (120F)
  • Maximum Differential Fuel Pressure: 7.0 Bar (101.5 psi)
  • Electrical Connector: USCAR
  • Fuel Compatibility
    • Methanol
    • Ethanol
    • MTBE
    • Nitromethane
    • All Known Hydrocarbon Fuels.

Fitment Table
